Product Overview

Engineered for modern commercial interiors, this glass partition wall system utilizes 12mm tempered safety glass panels with a minimum surface compression of 90 MPa, meeting ASTM C1048 and EN 12150 standards. The aluminum framing employs 6063-T5 alloy with a minimum wall thickness of 1.5mm, ensuring structural rigidity for room dividers up to 3000mm in height. Each panel is precision-cut with ±0.5mm tolerance for seamless assembly in office environments.

Key Specifications

Available Options

• Standard panel widths: 600mm, 800mm, 1000mm, 1200mm
• Glass finishes: clear, frosted, tinted (bronze/grey), or laminated with interlayer
• Frame colors: white (RAL 9016), black (RAL 9005), silver (RAL 9006), or custom RAL
• Connection types: T-junction, L-junction, or straight run with floor-mounted or ceiling-mounted tracks

Applications

• Open-plan office room dividers for separating workstations from meeting areas
• Glass partition walls in boutique retail stores for product display separation
• Modular room dividers in co-working spaces for flexible layout reconfiguration
• Glass panels for interior office corridors and reception area delineation

Customization Capabilities

Panel dimensions can be adjusted to fit specific floor-to-ceiling heights, with custom cutouts for electrical outlets or data ports. Frame profiles are available in 40mm, 50mm, or 60mm widths to match architectural design requirements.

Packaging & Shipping

Each glass panel is individually wrapped in PE foam and packed in reinforced wooden crates with foam corner protectors. Aluminum frames are bundled with protective film and shipped via LCL or FCL containers, with lead times of 20-25 days from order confirmation.

Why Choose Us

• Direct factory pricing with MOQ of 50 square meters for commercial projects
• Custom RAL color matching with 48-hour sample production for approval
• Third-party load testing reports available upon request for glass and frame assemblies

Frequently Asked Questions

What is the maximum panel height without requiring additional reinforcement?

Standard panels up to 3000mm height use a 1.5mm thick aluminum frame with 12mm glass. For heights exceeding 3000mm, we recommend upgrading to 15mm glass and a 2.0mm frame thickness, which can support up to 4000mm without intermediate posts.

Can the glass be customized with company logos or patterns?

Yes, glass can be digitally printed with ceramic frit or UV-curable inks for permanent designs. Screen-printed patterns or sandblasted logos are also available. Minimum order for custom printing is 20 square meters per design.

Is this system suitable for sound reduction between office zones?

Single 12mm tempered glass provides a sound transmission class (STC) rating of approximately 30. For higher acoustic performance, laminated glass with PVB interlayer (2.28mm) achieves STC 35-38. We recommend specifying acoustic glass if sound isolation is critical.

What is the minimum order quantity for a full office partition project?

For standard clear or frosted glass, the MOQ is 50 square meters. For custom RAL colors or printed glass, the MOQ increases to 100 square meters. Sample panels (1 sqm) are available for evaluation with a refundable deposit.

How are the panels secured to the floor and ceiling?

Panels are mounted using a continuous aluminum track system anchored to the floor and ceiling with expansion bolts (M8 or M10). The glass is held in place with rubber gaskets and aluminum caps, allowing for ±5mm adjustment during installation to accommodate uneven surfaces.
