Product Overview
Engineered for villa-grade residential applications, these aluminum casement windows utilize 6063-T5 aluminum alloy frames with thermal break profiles for enhanced insulation. The standard configuration incorporates Low-e double glazing (5mm + 12A + 5mm) to reduce UV transmission and improve energy efficiency, meeting EN 14351-1 performance standards for air permeability and water tightness.
Key Specifications
| Material | 6063-T5 aluminum alloy with thermal break |
| Frame Depth | 60mm (standard) / 70mm (optional) |
| Glass | 5mm Low-e + 12A air gap + 5mm clear tempered |
| Glazing Type | Double-glazed, argon-filled optional |
| Finish | Powder coating (RAL colors) or anodized silver/bronze |
| Max Size | 1500mm (W) x 2000mm (H) |
| Warranty | 5 years against manufacturing defects |
Available Options
- Size: Custom widths from 600mm to 1500mm, heights from 900mm to 2000mm
- Finish: 200+ RAL powder coat colors, wood grain finish, or silver/bronze anodized
- Hardware: Multi-point locking system (Hoppe or Roto), concealed hinges, handle options (aluminum, stainless steel)
- Glass: Low-e coated, argon-filled, laminated safety glass, or solar control coatings
Applications
- Villa master bedrooms requiring natural light with low heat gain
- Living room windows in high-end residential projects with strict energy codes
- Coastal homes needing corrosion-resistant frames and UV protection
- Architectural renovations upgrading to modern, energy-efficient glazing
Customization Capabilities
Frames can be customized to specific opening dimensions, with options for inward or outward opening, fixed or casement configurations, and integrated insect screens. Hardware and glass types are configurable to meet local building regulations and aesthetic preferences.
Packaging & Shipping
Each window is wrapped in protective film, secured with foam corner protectors, and packed in sturdy plywood crates for export. Standard shipping via sea freight (FOB or CIF) with lead time of 20-30 days after order confirmation.
Why Choose Us
- Direct factory pricing with no middlemen, supporting volume orders for villa projects
- ISO 9001:2015 certified production with consistent quality control on every batch
- Custom RAL color matching and Low-e glass coating options for unique architectural designs
Frequently Asked Questions
What is the heat transfer coefficient (U-value) of the standard Low-e glass configuration?
The standard 5mm Low-e + 12A + 5mm double glazing achieves a U-value of approximately 2.0 W/m²K, which improves to 1.6 W/m²K with argon gas fill. This meets typical residential energy efficiency requirements in temperate climates.
Can the window frames be customized with different thermal break widths?
Yes, the standard 60mm frame depth includes a 15mm polyamide thermal break. For enhanced thermal performance, we offer a 70mm frame depth with a 24mm thermal break, suitable for colder regions or passive house projects.
What is the maximum wind load resistance for these casement windows?
When installed per manufacturer guidelines, the standard frame with 5mm glass supports wind loads up to 1.2 kPa (class C3 per EN 12210). Upgraded frames with 6mm tempered glass can achieve 1.6 kPa (class C4).
Are these windows suitable for hurricane-prone regions?
Standard models are not rated for hurricane impact. However, we offer reinforced frames with laminated glass (6mm + 1.52mm PVB + 6mm) that meet ASTM E1886 and E1996 standards for impact resistance up to 80 mph debris.
What is the minimum order quantity and typical lead time for a villa project?
Minimum order is 50 square meters for custom sizes. Standard lead time is 25 days from design approval. For urgent projects, we can expedite to 15 days with a 10% surcharge on the order value.
Get A Quote
Contact us for customized quotation, volume pricing, and project specifications. Response within 24 hours.
Why Choose JUSEN
A Professional Door Manufacturer China Buyers Rely On
01
Energy Efficiency
02
Custom Manufacturing
03
Quality Control
04
Factory Capability
Technical Data
Technical Specifications
| Design Style | modern |
|---|---|
| Application | kitchen |
| Model Number | 90 series |
| Place of Origin | Shandong, China |
| Warranty | 3 Years |
