Aluminum Casement Wi | Aluminum Window China
Manufacturer in China
bedroom door. modern design. Custom sizes available. OEM/ODM from JuSen factory, China. Lifetime warranty.
- Factory Direct Manufacturer
- OEM & ODM Available
- Custom Size Production
- Global Export Experience
Product Overview
Engineered from 6063-T5 aluminum alloy with a double-glazed, soundproof configuration specifically designed for villa environments. Thermal break profiles and multi-chambered frames reduce acoustic transmission to residential noise standards, achieving STC ratings of 32-38 depending on glass specification.
Key Specifications
| Material | 6063-T5 aluminum alloy, 1.8mm wall thickness |
| Door Thickness | Frame depth: 60mm |
| Fire Rating | N/A (non-fire-rated product) |
| Core | Hollow aluminum profile with thermal break |
| Finish | Powder-coated (RAL colors) or anodized (silver, bronze) |
| Max Size | 1500mm x 2000mm |
| Warranty | 5 years against manufacturing defects |
Available Options
- Size: custom widths from 600mm to 1500mm, heights from 1000mm to 2000mm
- Finish: 200+ RAL colors, wood grain texture, or brushed anodized
- Hardware: multi-point locking system (Hoppe or similar), concealed hinges, optional mosquito mesh
- Glass: double-glazed 4mm+12A+4mm or 5mm+12A+5mm, with optional Low-E coating
Applications
- Villa living rooms requiring reduced street noise
- Master bedroom windows in suburban detached homes
- Home office windows facing busy roads
- Second-floor windows in multi-story residential villas
Customization Capabilities
Frame color can be matched to existing villa trim or RAL code. Glass thickness and gap width adjustable for specific sound reduction targets (up to 5mm+20A+5mm).
Packaging & Shipping
Each window unit packed in reinforced cardboard with foam inserts, then wooden crating for export. FOB or CIF terms available via sea freight to major ports.
Why Choose Us
- Direct factory pricing with 20 Years of aluminum window export experience
- Custom sizes and colors produced in 15 working days for standard orders
- All frames tested for air permeability (Class 6) and watertightness (Class 9A) per EN 12207
Frequently Asked Questions
What acoustic performance can I expect from the double-glazed configuration?
With standard 4mm+12A+4mm glass, the window achieves STC 32. Upgrading to 5mm+12A+5mm with laminated inner pane reaches STC 38, suitable for reducing traffic noise by 30-40 decibels.
Can the frame color be customized to match my villa’s existing windows?
Yes, any RAL color is available with a minimum order quantity of 10 units. Custom colors require an additional 3-5 working days for powder coating setup.
Is this window suitable for ground-floor villas with high security needs?
Yes, the multi-point locking system (standard 3-point or optional 5-point) combined with 1.8mm frame thickness provides break-in resistance comparable to standard security windows.
What is the minimum order quantity for a villa project?
Minimum order is 10 units per size/color combination. For smaller quantities, we offer standard sizes (1200x1500mm) in stock colors (white, grey, bronze) with no minimum.
How is the glass sealed to prevent condensation between panes?
Double glazing uses a warm-edge spacer bar with butyl sealant and secondary silicone seal. Each unit is tested for dew point at -20°C to ensure no internal fogging for 10+ years.
Get A Quote
Contact us for customized quotation, volume pricing, and project specifications. Response within 24 hours.
Why Choose JUSEN
A Professional Door Manufacturer China Buyers Rely On
01
Energy Efficiency
02
Custom Manufacturing
03
Quality Control
04
Factory Capability
Technical Data
Technical Specifications
| Design Style | modern |
|---|---|
| Application | bedroom |
| Opening Method | swing |
| Model Number | 120 Series-A |
| Place of Origin | Hebei, China |
| Warranty | Lifetime |
Need A Custom Specification?
- Technical drawings & CAD support
- Sample production before mass order
- Test reports on request
- Container loading plan
Engineering
Designed For Performance
- 01 Material Selection — Premium materials are selected according to different applications to ensure durability and long-term performance.
- 02 Precision Manufacturing — Advanced production processes and skilled craftsmanship ensure consistent quality from raw materials to finished products.
- 03 Structural Performance — Engineered structures provide strength, stability and reliable operation for different project requirements.
- 04 Quality Control — Strict inspection procedures maintain consistent standards before shipment.
- 05 Custom Configuration — Flexible options for dimensions, finishes, hardware and specifications to meet different architectural requirements.
- 06 Long Service Life — Designed for durability with reliable materials, protective treatments and professional manufacturing.
Manufacturing Capability
From Factory Production To Global Projects
STEP 01
Material Inspection
STEP 02
Precision Processing
STEP 03
Assembly
STEP 04
Quality Testing
STEP 05
Export Packing
120+
Production Capacity
Monthly output for container-scale project orders.
35+
Manufacturing Equipment
CNC centres, cutting, milling and automated assembly lines.
18+
Quality Control
Inspection checkpoints across the full production flow.
800+
Export Experience
Countries served across residential and commercial projects.
Applications
Built For Residential And Commercial Projects
Residential Villa
Apartment Building
Hotel Project
Commercial Building
Related Solutions
OEM Doors And Windows Solutions By Project Type
Residential Door & Window Solution
Commercial Building Solution
Hotel Project Solution
Villa Customized Solution
OEM / ODM
OEM Doors And Windows Customization Service
Custom Dimensions
Custom Colors
Custom Glass
Custom Hardware
Private Label
01
Requirement Analysis
02
Engineering Design
03
Sample Confirmation
04
Mass Production
05
Shipment
Global Projects
Delivered Worldwide By A China Door Manufacturer
United States
USA Villa Project
Australia
Australia Residential Project
Middle East
