Product Overview

6063-T5 aluminum alloy with a thickness of 1.5mm for the main frame and 0.8mm for the infill panels ensures structural integrity for perimeter security. Each section is powder-coated with a 60-micron layer for UV resistance and corrosion protection, tested to ASTM B117 salt spray standards for 500 hours. This garden fence system utilizes a modular panel design with interlocking brackets for straightforward layout adjustments.

Key Specifications

Available Options

• Panel widths: 1200mm, 1500mm, 1800mm, 2400mm
• Standard heights: 900mm, 1200mm, 1500mm, 1800mm
• RAL color choices: 7016 (anthracite gray), 6005 (moss green), 9005 (jet black), 9010 (pure white)
• Post caps: flat, ball, or spear-top designs in matching finish
• Gate integration: single or double swing gates, sliding gate option for wider openings

Applications

• Residential property boundary fencing for detached homes and townhouses
• Perimeter enclosure for private gardens, patios, and pool areas
• Commercial landscaping for office parks, retail plazas, and public parks
• Security screening for schools, community centers, and playgrounds

Customization Capabilities

Custom panel widths and heights can be fabricated to match non-standard property lines, with bespoke RAL color matching available for projects requiring brand-specific hues. Infill patterns can be adjusted from standard vertical slats to horizontal or diamond lattice designs, and integrated post lighting options are available for illuminated perimeters.

Packaging & Shipping

Each panel and post set is individually wrapped in protective foam sheeting and packed in heavy-duty corrugated cartons, with corner protectors for transit. Standard shipping is via sea freight in 20ft or 40ft containers, with FOB or CIF terms available for global destinations.

Why Choose Us

• Direct factory pricing with no middleman markups, enabling competitive margins for distributors and wholesalers
• Full traceability of raw materials from certified aluminum billet suppliers, ensuring consistent alloy composition
• 15-year warranty against rust, peeling, and structural defects, backed by a dedicated after-sales team

Frequently Asked Questions

What is the expected lifespan of the powder coating in coastal environments?

The 60-micron polyester powder coating is tested to 500 hours of salt spray exposure per ASTM B117, which correlates to approximately 10-20 Years in moderate coastal conditions. For high-corrosion zones (direct sea spray), we recommend an additional clear topcoat or upgrading to a PVDF coating for extended durability.

Can the fence panels be cut to size on-site if needed?

Panels are pre-cut to specified dimensions at the factory to maintain the integrity of the powder coating. On-site cutting with a metal saw will expose raw aluminum edges; these must be sealed with a touch-up paint kit (supplied with each order) to prevent corrosion. For best results, order exact custom sizes during production.

What type of posts and foundations are required for installation?

Standard posts are 60mm x 60mm hollow aluminum with a 2.0mm wall thickness, designed for concrete footing embedment of 400mm depth. For areas with high wind loads (above 120 km/h), we recommend 80mm x 80mm posts with deeper footings. Post caps and base plates are included for ground-level or wall-mounted configurations.

What is the minimum order quantity for a container shipment?

For a 20ft container, the minimum order is approximately 150 linear meters of paneling (based on 1800mm height panels). For a 40ft container, the minimum is around 300 linear meters. Smaller orders (by air or LCL sea freight) are possible with a higher per-unit cost and extended lead time.

How are the fence panels packed to prevent damage during transit?

Each panel is separated by foam interlayers and wrapped in a 3-layer protective film, then packed in a wooden crate with corner brackets. Posts are bundled separately with plastic strapping. All cartons are palletized and shrink-wrapped for container loading, with a loading report and photos provided before shipment.
