Product Overview

Engineered from 6063-T5 aluminum alloy, this interior casement door combines a sleek minimalist profile with double-sided 5mm grey frosted patterned glass to achieve a sound reduction of up to 32 dB. The aluminum frame features a 20mm sightline with powder-coated finish, designed specifically for kitchen environments where light diffusion and acoustic privacy are required.

Key Specifications

Available Options

• Single or double leaf configurations
• Custom RAL powder-coated colors (matte or gloss)
• Concealed hinges or standard butt hinges in stainless steel
• Frosted patterned glass variants: rain, sandblasted, or geometric lines

Applications

• Kitchen-to-dining room partitions requiring light privacy
• Apartment interior doors between living and cooking areas
• Modern office pantry entrances with noise reduction needs
• Hotel suite kitchenette doors for guest acoustic comfort

Customization Capabilities

Frame width can be adjusted from 30mm to 50mm, glass thickness from 4mm to 8mm, and patterned glass designs customized per project requirement. Hardware positions and handle styles are configurable without MOQ for orders above 50 units.

Packaging & Shipping

Each door is individually wrapped in PE foam and corrugated cardboard, then packed in plywood crates with edge protectors. FOB shipping from Ningbo port with 15-25 days lead time for standard orders.

Why Choose Us

• 20+ years exporting aluminum doors to 60+ countries with consistent quality control
• In-house powder coating line ensures color consistency across large orders
• Full testing reports available for sound insulation and glass safety compliance

Frequently Asked Questions

What is the actual sound reduction rating of the grey frosted patterned glass?

The double-sided 5mm tempered glass with grey frosted interlayer achieves a Sound Transmission Class (STC) of 32 dB per ASTM E413 testing, reducing normal conversation to a faint murmur. Thicker 8mm glass options can reach STC 36 dB.

Can the frosted pattern be customized to match our project branding?

Yes, the patterned glass can be customized with your logo, geometric patterns, or specific frost density. Minimum order for custom pattern is 100 doors, with tooling cost of $200-$500 depending on complexity.

Is this door suitable for humid kitchen environments near stoves?

Aluminum frame with powder coating is corrosion-resistant up to 500 hours salt spray test. The tempered glass withstands thermal shock up to 200°C. Not recommended for direct steam exposure from commercial dishwashers.

What hardware options are available for concealed hinges?

We offer stainless steel concealed hinges with 3D adjustment (height, depth, side) rated for 40kg per door leaf. Standard finish is satin stainless steel, with black or white powder coating available on request.

How are the doors packed to prevent glass breakage during sea freight?

Each glass unit is separated with foam corner protectors and wrapped in anti-scratch film. Doors are stacked vertically in plywood crates with internal bracing. Breakage rate is below 0.3% based on 2023 shipping data.

Get A Quote

Contact us for customized quotation, volume pricing, and project specifications. Response within 24 hours.
