Double, glazed Insulated Apartment Panoramic Aluminum Alloy Folding Soundproof Casement Windows Stainless Steel Screen Horizontal. minimalist, exterior, folding, PK60-1
| Design Style | minimalist |
|---|---|
| Application | exterior |
| Opening Method | folding |
| Model Number | PK60-1 |
| Place of Origin | Hebei, China |
Product Overview
Engineered for apartment living, this panoramic aluminum alloy folding casement window integrates double-glazed insulated units with a 6063-T5 aluminum alloy frame for enhanced acoustic and thermal performance. The horizontal folding design maximizes natural light and ventilation, while a built-in stainless steel screen provides insect protection without compromising the clean sightlines.
Key Specifications
| Material | 6063-T5 aluminum alloy frame |
| Door Thickness | Frame profile: 1.8 mm wall thickness |
| Fire Rating | Not applicable (non-fire-rated product) |
| Core | Empty frame with double-glazed insulated glass units (5+12A+5 mm) |
| Finish | Stained wood grain or solid color powder coating (RAL options) |
| Max Size | Single panel: 900 mm (W) x 2400 mm (H) |
| Warranty | 5 years against manufacturing defects |
Available Options
- Custom panel dimensions within max size limits
- Stained finishes: oak, walnut, mahogany, or custom RAL colors
- Stainless steel screen mesh: 304 grade, 18×16 mesh count
- Double-glazed glass options: clear, low-E, or tinted
Applications
- High-rise apartment balcony enclosures requiring sound reduction from street noise
- Residential living room extensions to create open-plan indoor-outdoor spaces
- Apartment kitchen windows needing thermal insulation and insect screening
- Residential sunrooms or conservatories where panoramic views are prioritized
Customization Capabilities
Panel dimensions, frame color, glass type, and screen mesh density can be tailored to project specifications. Hardware color (black, silver, or white) is selectable to match interior design.
Packaging & Shipping
Each folding window is disassembled into panel units, wrapped in protective foam and cardboard, then crated for export. FOB shipping from Chinese ports with standard 20-30 day lead time for custom orders.
Why Choose Us
- Factory-direct pricing with 15+ years of aluminum window production experience
- Full 5-year warranty on frame structure and hardware
- ISO 9001 certified manufacturing with consistent quality control
Frequently Asked Questions
How does the double-glazed unit achieve acoustic insulation?
The 5+12A+5 mm double glazing uses a 12 mm air gap with desiccant-filled spacer bars, reducing sound transmission by up to 35 dB depending on glass type. Low-E coating further improves thermal performance by reflecting infrared heat.
Can the window dimensions be customized for non-standard openings?
Yes, each panel can be built to custom widths and heights up to 900 mm x 2400 mm. The total folding system width is limited only by structural support requirements, typically up to 6 meters for residential use.
What type of stainless steel screen is included?
The screen uses 304 grade stainless steel wire with 18×16 mesh count (18 wires per inch horizontally, 16 vertically), offering insect exclusion while maintaining 70% light transmission and resistance to corrosion in coastal environments.
What is the minimum order quantity for custom sizes?
Standard minimum order is 10 square meters per project. Smaller quantities may be accommodated at slightly higher unit pricing. Volume discounts apply for orders exceeding 50 square meters.
How are the folding windows packaged for export?
Each panel is individually wrapped with foam and cardboard, then packed into wooden crates with internal bracing. Hardware and screens are bagged and secured. Crate dimensions are optimized for 20 ft or 40 ft container loading.
Get A Quote
Contact us for customized quotation, volume pricing, and project specifications. Response within 24 hours.
Built For Stable Production & Global Supply
Integrated manufacturing workflow covering production, quality control, export packaging, and container loading.
Factory
Modern manufacturing facilities designed for stable production capacity and international export supply.
Production
Standardized production workflow ensures consistent quality and efficient order management.
CNC Processing
Precision CNC equipment improves dimensional accuracy and manufacturing consistency.
Spray Line
Professional surface finishing systems support stable coating quality and color consistency.
Quality Control
Dedicated QC inspections are carried out during production and before shipment.
Packaging
Reinforced export packaging protects products during international transportation.
Container Loading
Optimized loading plans improve shipping efficiency and reduce transportation risks.
Frequently Asked By Global Buyers
Common questions about MOQ, production, customization, export packaging, shipping, and OEM cooperation.
Our MOQ depends on product type, finishes, and customization requirements. Mixed container orders are supported.
Standard lead time is usually 15–35 days after confirming drawings, finishes, and deposit payment.
Yes. OEM, logo branding, custom packaging, and exclusive product configurations are available.
We provide Chinese, German, and Italian hardware options based on market and project requirements.
Selected systems are available with FD30 and FD60 fire-rated configurations for commercial projects.
We export to Europe, North America, the Middle East, Southeast Asia, Australia, and other global markets.
Products use reinforced export packaging with foam protection, corner guards, and waterproof wrapping.
Yes. Custom sizes, finishes, colors, glass options, and architectural adaptations are supported.
