Wood Grain Steel Security Door – Custom Commercial Design

Product Overview

Engineered from 16-gauge galvanized steel sheets with a cold-rolled core structure, this security door features a multi-layer wood grain coating applied via electrostatic powder finishing for commercial environments. Certified to ASTM E330 structural performance standards with reinforced hinge zones and a 3-point locking system integration, the design meets the demands of high-traffic commercial applications.

Key Specifications

Available Options

• Custom sizes: width from 30 to 48 inches, height from 72 to 96 inches
• Wood grain finish colors: dark walnut, mahogany, oak, cherry, and custom RAL matching
• Hardware: 3-point or 5-point locking system, heavy-duty hinges, panic bar compatible
• Glass options: no glass (solid security door) or optional 1/4-inch laminated security glass

Applications

• Back-of-house security doors in hotel and hospitality complexes
• Entrance doors for retail storefronts requiring high durability
• Security doors for office building corridors and server rooms
• Perimeter doors for warehouses and distribution centers

Customization Capabilities

Custom dimensions, wood grain color matching to existing architectural finishes, and reinforcement levels for specific security requirements can be accommodated. Integration of electronic access control or magnetic locks is supported through pre-cut hardware preparations.

Packaging & Shipping

Each door is individually wrapped in protective foam and corrugated cardboard, then packed in wooden crates for export. FOB shipping from main Chinese ports with standard lead time of 20-25 working days after order confirmation.

Why Choose Us

• Direct factory production with in-house powder coating line ensuring consistent wood grain finish
• Custom engineering support for non-standard security door requirements
• Volume pricing available for wholesale and project orders with MOQ flexibility

Frequently Asked Questions

What steel gauge is used for the door skin and how does it affect security?

The door skin is made from 16-gauge galvanized steel (1.52 mm thickness), which provides a balance between weight and structural rigidity. This gauge is standard for commercial security applications, resisting forced entry while being suitable for standard commercial door frames. Thicker gauges (14-gauge) can be custom ordered for higher security zones.

Can the wood grain finish be matched to existing doors or architectural samples?

Yes, the electrostatic powder coating process allows for custom color matching. Send a physical sample or RAL/Pantone code, and our factory can produce a matched wood grain texture. Minimum order for custom color is 50 units to justify color formulation setup.

Is this door suitable for exterior use in coastal or humid environments?

The galvanized steel core and powder-coated wood grain finish provide corrosion resistance suitable for most commercial environments. For direct coastal exposure or high-humidity areas, we recommend an additional anti-corrosion primer treatment, available as a customization option at no extra cost for orders over 100 units.

What locking systems are compatible with this door for commercial projects?

The door is prepped for standard 3-point locking systems using deadbolts and latch guards. It is compatible with most commercial-grade mortise locks, panic bars, and electronic access control systems. Custom cutouts for magnetic locks or keypad entry can be added during production.

What is the lead time for a wholesale order of 50 units with custom color?

Standard lead time for custom color orders is 25-30 working days from confirmed payment and color approval. For standard wood grain colors (dark walnut, mahogany, oak), lead time reduces to 20 working days. Shipping via sea freight from Shanghai takes approximately 15-25 days depending on destination port.
