Product Overview

Constructed from 16-gauge galvanized steel with a fully welded frame, this modern entrance door integrates a pre-installed smart lock system for enhanced access control in commercial and multi-family residential buildings. The door features a C-channel steel core with polyurethane foam insulation, achieving a 1.8 U-factor for energy efficiency, and meets ANSI/BHMA A156.2 Grade 1 operational standards for heavy-duty cycle use.

Key Specifications

Available Options

• Standard sizes: 36 in x 80 in, 36 in x 84 in, 42 in x 96 in; custom sizes up to 48 in x 96 in
• Finish options: RAL 9016 (white), RAL 9005 (black), and custom RAL colors; simulated wood-grain laminate (oak, walnut)
• Hardware options: Pre-installed smart lock with keypad, fingerprint, and RFID access; optional mechanical deadbolt backup; lever or push/pull handle sets in satin nickel or matte black
• Glass options: Dual-pane tempered low-E glass (1/2 in) with argon fill; optional frosted or laminated glass for privacy

Applications

• Main entrance doors for apartment complexes and multi-tenant residential buildings
• Security doors for commercial office lobbies and shared facility entries
• Rear or side entrance doors for retail stores and small business premises
• Interior security doors for server rooms, utility closets, and restricted storage areas

Customization Capabilities

Custom dimensions, RAL finishes, smart lock integration (Zigbee, Z-Wave, or Wi-Fi protocols), and reinforced hinge plates for high-traffic applications can be specified. Additional options include magnetic door holders, electric strikes, and access control system compatibility.

Packaging & Shipping

Each door is packed in a corrugated cardboard box with foam corner protectors, edge guards, and a plastic moisture barrier. Shipments are consolidated on pallets and wrapped with stretch film; FOB Shanghai or CIF to major ports, with 25-35 day lead time for standard orders.

Why Choose Us

• Direct factory pricing with no middleman markup; minimum order quantity of 10 units per specification
• In-house steel fabrication and powder coating line ensures consistent gauge thickness and surface finish
• Full quality control including flatness testing, lock alignment checks, and 200,000-cycle hinge durability testing

Frequently Asked Questions

What is the lock type and can it be integrated with existing access control systems?

The door comes pre-installed with a Grade 1 smart lock featuring keypad, fingerprint, and RFID card access. The lock supports Wiegand output and can be integrated with third-party access control panels via dry contact relays. Customizable to support Zigbee, Z-Wave, or Wi-Fi protocols for networked systems.

Can the door be customized with a different RAL color or wood-grain laminate?

Yes, the door can be finished in any RAL color with a polyester powder coating. For a wood-grain appearance, a simulated laminate (oak or walnut) can be applied. Minimum order quantity for custom RAL is 20 units; for laminate, 50 units.

Is this door suitable for exterior use in a commercial building?

Yes, the 16-gauge galvanized steel and polyurethane foam core provide resistance to moisture and thermal transfer, making it suitable for exterior entrances in commercial or multi-family buildings. For harsh coastal or high-humidity environments, additional galvanizing or stainless steel hardware is recommended.

What is the minimum order quantity for a custom size and how long does it take?

Custom sizes up to 48 in x 96 in require a minimum order of 10 units per size. Lead time for custom dimensions is 35-45 days, including tooling and frame fabrication. Standard sizes ship within 25-30 days.

How is the door packaged to prevent damage during shipping?

Each door is individually boxed with foam corner protectors and edge guards, then placed on a pallet with a plastic moisture barrier. The entire pallet is stretch-wrapped and banded. For sea freight, additional desiccant packs are added to prevent condensation damage.

Get A Quote

Contact us for customized quotation, volume pricing, and project specifications. Response within 24 hours.
