Solid Wood Barn Door Soundproof Sliding with Hardware Kit

Product Overview

Crafted from kiln-dried solid wood species including oak, walnut, and mahogany, this interior barn door achieves a Sound Transmission Class (STC) rating of 32 through a multi-layer core construction with acoustic-grade mass-loaded vinyl (MLV) barrier. The complete hardware kit includes a cold-rolled steel track rated for 150 lbs, nylon-reinforced roller hangers with sealed ball bearings, and a floor-mounted guide system, meeting ANSI/BHMA A156.14 Grade 1 standards for sliding door hardware.

Key Specifications

Available Options

• Size: custom widths from 24″ to 48″, heights from 72″ to 96″
• Finish: 12 standard wood stains plus RAL color matching
• Hardware: matte black, brushed nickel, oil-rubbed bronze, or satin chrome track and hangers
• Glass: optional 1/4″ tempered laminated glass insert in clear, frosted, or ribbed patterns

Applications

• Home theater or media room sound isolation doors
• Private office or conference room sliding partitions
• Master suite en-suite bathroom or walk-in closet entrances
• Recording studio or music practice room interior doors

Customization Capabilities

Door dimensions, wood species, panel profile (flat, raised, or recessed), and stain color can be fully customized per project specifications. Hardware finish and glass insert styles are also selectable to match architectural requirements.

Packaging & Shipping

Each door is individually wrapped in heavy-duty corrugated cardboard with foam corner protectors and edge guards, then crated in a plywood frame. Hardware is packed separately in a labeled box. Standard export packaging meets ISTA 3A testing standards for freight shipment.

Why Choose Us

• Factory-direct pricing with 500+ unit monthly production capacity for solid wood sliding doors
• In-house CNC machining ensures ±0.5 mm precision on all panel dimensions and cutouts
• All doors pre-drilled for hardware and include full assembly instructions in English

Frequently Asked Questions

What is the actual STC rating achieved with this door and how is it measured?

This door achieves an STC 32 rating when tested per ASTM E413 in a standard partition assembly. The rating is achieved through a 1-3/8 inch solid wood core with a 6 mm MLV septum layer and acoustic-grade perimeter seals. Actual field performance depends on gap sealing at the bottom and header.

Can the door be customized with a specific wood species not listed in the options?

Yes, custom wood species such as cherry, ash, teak, or white oak can be sourced for larger orders (minimum 20 units per species). Lead time for non-standard species is typically 4-6 weeks additional for material procurement and moisture conditioning.

Is this door suitable for a soundproofing application between a home theater and an adjacent bedroom?

Yes, for typical residential interior walls with standard 2×4 stud construction and insulation, this door provides a significant reduction in airborne noise transmission. For maximum performance, we recommend pairing with acoustic door bottom seals and a threshold plate, which can be supplied as an add-on kit.

What are the minimum order quantities for custom sizes and finishes?

Single-unit orders are accepted for standard sizes and stains. Custom sizes require a minimum order of 5 units per dimension. Custom color matching requires a minimum order of 10 units per color, with a one-time setup fee of $50 for color formulation.

How is the hardware kit packaged and what is the typical lead time for shipment?

The hardware kit is packed in a separate sealed box with all components labeled individually. Standard lead time is 15-20 working days for production and packaging. Express production (10 working days) is available for orders of 50 units or fewer at a 15% surcharge.

Get A Quote

Contact us for customized quotation, volume pricing, and project specifications. Response within 24 hours.
