Product Overview

Engineered for expansive openings, this sliding balcony door utilizes extruded 6063-T5 aluminum alloy frames with a multi-chamber thermal break profile. Double-glazed tempered glass units with 12mm air gaps provide acoustic insulation and reduce thermal transfer for residential and commercial balcony enclosures.

Key Specifications

Available Options

• Custom widths from 1200mm to 3000mm; heights from 1800mm to 2400mm
• RAL powder coat colors: white, grey, black, bronze, or custom match
• Low-E glass coating for improved thermal performance
• Laminated glass option for enhanced security

Applications

• High-rise apartment balcony enclosures in coastal climates
• Hotel terrace sliding doors for guest room access
• Residential patio doors in multi-family housing developments
• Commercial office break room balcony access points

Customization Capabilities

Frame color matched to RAL codes, glass type selection (clear, frosted, Low-E), and size adjustments within 3000mm x 2400mm per panel. Handle and lock hardware can be specified to match project standards.

Packaging & Shipping

Each door panel packed in corrugated cardboard with foam corner protectors and wooden crating for export. Standard FOB shipping from Chinese ports with 20-30 day lead time for production.

Why Choose Us

• Factory-direct pricing with no middleman markup
• Custom sizes accepted without tooling change fees
• Double-glazed units factory sealed to prevent condensation

Frequently Asked Questions

What is the standard glass thickness for this sliding balcony door?

Standard configuration is 5mm tempered glass on each side with a 12mm air gap, totaling 22mm thick double-glazed units. Low-E coating or 6mm glass can be specified for higher thermal or acoustic requirements.

Can the frame color be matched to existing building colors?

Yes, powder coating can be matched to any RAL color code. Minimum order quantity for custom colors is 50 square meters. Standard RAL 9016 white, RAL 7016 grey, and RAL 9005 black are available without MOQ restrictions.

Is this door suitable for windy balcony locations in high-rise buildings?

Yes, the 6063-T5 aluminum frame with 1.6mm wall thickness and double-glazed tempered glass withstands wind loads up to 1.5 kPa as tested per EN 12210. For extreme wind zones, reinforced frame profiles are available.

What locking mechanism is included with the sliding door?

JuSen Doorsludes a multi-point locking system with a hook lock at the meeting stile and a flush bolt at the bottom track. Keyed handle or thumb-turn options are available for different security requirements.

How are the double-glazed units sealed to prevent fogging?

Glass units are factory assembled with a butyl primary seal and silicone secondary seal. A desiccant-filled aluminum spacer bar absorbs residual moisture. Units carry a 5-year warranty against seal failure or internal condensation.

Get A Quote

Contact us for customized quotation, volume pricing, and project specifications. Response within 24 hours.
