304 Stainless Steel Fire-Rated Doors with Glass – Laboratory

Product Overview

Engineered for high-traffic commercial environments, these 304 stainless steel metal and glass fire-rated doors combine structural integrity with aesthetic transparency. Constructed with a 16-gauge 304 stainless steel frame and integrated fire-rated glass, they meet UL 10C and BS 476 standards for up to 90-minute fire protection. The airtight laboratory-grade design ensures smoke containment and environmental control, while the stained finish provides a sophisticated appearance suitable for hotel entrances.

Key Specifications

Available Options

• Size options: custom widths from 800-1200 mm, heights from 2000-2400 mm
• Finish options: brushed satin, mirror polish, or custom stain colors
• Hardware options: stainless steel lever handles, panic bars, or push/pull plates
• Glass options: clear, frosted, or wire-reinforced fire-rated glass up to 60-minute rating

Applications

• Hotel main entrances requiring fire-rated separation with visible aesthetics
• Laboratory cleanrooms needing airtight seals for pressure control and contamination prevention
• Commercial office corridors where smoke containment and durability are critical
• Hospital isolation rooms demanding hygienic, non-porous surfaces with fire protection

Customization Capabilities

Customizable dimensions, glass configurations (single or double glazing), and lock types including electronic access control integration. Stained finish colors can be matched to specific RAL or custom swatches for brand consistency.

Packaging & Shipping

Each door is packed with edge protectors, foam padding, and reinforced cardboard wrapping for export. FCL and LCL shipments available with lead time of 20-30 days after order confirmation.

Why Choose Us

• Factory-direct pricing with 10+ years of export experience to commercial projects
• Third-party fire certification documentation provided with every order
• Custom fabrication for non-standard sizes without additional tooling fees

Frequently Asked Questions

What fire certifications do these doors hold?

These doors are certified to UL 10C for positive pressure fire tests and BS 476 Part 22 for up to 90-minute fire resistance. Certification documents from accredited labs are available upon request.

Can the stained finish be customized to match existing hotel decor?

Yes, the stainless steel surface can be stained to match specific RAL or Pantone colors. Samples are provided for approval before production, with a minimum order quantity of 10 units for custom colors.

Are these doors suitable for airtight laboratory environments?

Yes, the frame includes a continuous gasket seal and adjustable compression hinges to achieve airtight performance meeting ASTM E283 standards for air leakage. Optional pressure relief vents can be integrated for lab applications.

What is the maximum glass size for the fire-rated panel?

The maximum single glass panel is 600 mm x 900 mm for a 60-minute rating. Larger openings require multiple panels or a reduced fire rating of 45 minutes. All glass is ceramic or wired for impact resistance.

What is the lead time for international orders?

Standard lead time is 20-25 working days for non-custom sizes, and 25-30 days for fully customized units. Express shipping via air freight is available for urgent projects at additional cost.

Get A Quote

Contact us for customized quotation, volume pricing, and project specifications. Response within 24 hours.
